Access Reader (Wiegand) AR-661 (UG-V2) 1 ar_661_ug_v2

AR-661 (UG-V2)

Name
Long Range Reader

Features
• Long Range Proximity Reader
• Flexible to integrate with SOYAL or other access control system
• Interface of the Proximity Reader have WG and ABAII etc., depending on the controller to make adjustments
• 3 LED and 1 beeper for identification
• Builtin Watchdog to prevent system from hanging

Spceification
Frequency	922-928MHz
Power Supply	12VDC
Standard	ISO 180006C
Reading Range	4-6 M
Read / Write	Read Only
Power Consumption	<18W
Communication Interface	Wiegand
	RS-232
Data Transfer Rate	9600 bps(N,8,1)
Operating Temperature	100%:-35℃ to +45℃ / 50%:-35℃ to +65℃
Keypad Material	No
Indicator	1 LED
Protection Standard	IP65
Housing Material	ABS
Color	Ivory
Dimensions(mm)	228(L)X228(W)X52(H)
Weight(g)	940±50
Patent	FCC Part 15
	NCC,IC,CE
